24 Electric+2 Optic Management Gigabit Fiber Network Switch UKG2602GC manufacturer from China Shenzhen Speed Technology Co.

24 Electric+2 Optic Management Gigabit Fiber Network Switch

Special Groups:	management switch (9)
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: UKG2602GC

24 Electric+2 Optic Management Gigabit Fiber Network Switch UKG2602GC provides 1000Mbps speed and the switching capacity of up to 50Gbps,plug-n-play.

24 Electric+2 Optic Management Gigabit Fiber Network Switch UKG2602GC is a Gigabit managed switch with 24 10/100/1000M RJ45 ports and 2 SFP optical ports, which supports IEEE802.3/u/x/z Standard. As high power design, the peak of power output of up to 60W with stable and reliable performance. Users can set a variety of functions of switches through Ethernet port by the form of WEB, and the network administrator can login switch to set each port as well as monitoring and controlling. In addition, UKG2602GC is also equipped with many useful functions: Qos, VLAN, Port Trunking, Bandwidth Control, port security , which is very suitable for working group and MAN edge application.

Product features:

1.Qos: You can choose two queuing system, strict priority queue (SPQ) and weighted round-robin (WRR), WRR defines seven kinds of priorities and four priority queue.

2.Support for port mirroring.

3.Support for storm suppression.

4.VLAN: Support for port-based VLAN and 802.1Q-based VLAN, in which the 802.1Q-based VALN can support up to 256 dynamic VLAN, VLAN ID scope: 1-4094.

5.Port trunking: Support static port aggregation and in line with the IEEE 802.3ad LACP protocol port aggregation.

6. Bandwidth Control: Support the bandwidth control of inlet and outlet per port.

Product specification:

Product model	UKG2602GC
Supported agreement	IEEE802.3\IEEE 802.3u\IEEE 802.3ab\IEEE 802.3x\IEEE802.3z\IEEE802.1q\IEEE802.1p\IEEE802.1ak
Number of port	24 RJ45 port, 2 SFP optical port.
Network Media	1000Base-LX: using long wavelength laser (1310nm) across multi-mode and single-mode fiber, the maximum distance of multi-mode fiber is 550m, single mode is 10-24km. 1000Base-SX: using 62.5 μ m multi-mode fiber, the maximum transmission distance is 275m, using 50 μ m multimode fiber, the maximum transmission distance is 550 meters. 10Base-T: cate-3 or more UTP; (support maximum transmission distance of 200m), 14880P/S 100Base-TX: cate-5 UTP; (support maximum transmission distance of 100m), 148800P/S) 1000Base-T:Cate-5 UTP or 6 UTP; (support maximum transmission distance of 100m), 1488000P/S)
Maximum packet length	9216B
VLAN address table	4K
MAC address table	8K
Cache	4Mb
The backplane bandwidth	50Gbit
Filtering and forwarding	10Mbps:14880pps 100Mbps:148800pps 1000Mbps:1488000pps
LED indication	Work on 1000M, 100M/10M respectively in green, yellow light indicates
Dimensions	440x230x44mm (1U19 inch standard chassis)
Use of the environment	Operating temperature: 0 ℃ ~ 40 ℃; operating humidity: 10% to 90%, non-condensing Storage temperature: -20 ℃ ~ 70 ℃; storage humidity:5% to 90%, non-condensing
Power	Input:90-264VAC,50-60HZ; Output: 5V/12A
Power consumption	Maximum power: 60W
